40' Low Profile Gooseneck Tri-Axle Trailer with Hydraulic Dovetail

Previously Owned - Recent CVIP

2024 LOW PROFILE GOOSENECK 40FT W/9FT HYDRAULIC DOVETAIL (102" X 40')

Additional Trailer Specifications:

• GVWR: 30,000 lbs
• TARE: 11,040 lbs
• Max Paylaod: 18960 lbs
• Tires: ST215/75R17.5
• Axles: 3 axles, 12,000 lbs per axle
• Suspension: Heavy-duty leaf spring for smooth towing and load absorption
• Brakes: Electric brakes on all axles for efficient stopping power
• Coupler: Gooseneck
• Decking: Steel frame, treated wood and optional dovetail design for easy loading/unloading
• Ramp: Dovetail ramps for loading heavy equipment
• Tire Size: ST215/75R17.5 tires
• Lighting: LED lights for road safety compliance
• Toolbox: Front-mounted toolbox for secure storage of chains, straps, and other tie-down equipment
• 34" HIGH DECK - LOW PROFILE, 4" LOWER THAN STANDARD DECK, EASIER TO LOAD LOW CLEARANCE EQUIPMENT/VEHICLES
• LED LIGHTS, full LED package
• LED BACKUP LIGHTS - backup safely in dark

• -SINGLE ROW L.E.D. LIGHT BAR UP ON TOP OF GOOSENECK - lights up the night, load or unload safely in dark
  8 BUTTON WIRELESS REMOTE CONTROL FOR 9FT HYDRAULIC DOVETAIL,
  HYDRAULIC JACKS AND 17,500LB WINCH - safety first, allows operator to operate from any location
• MUD FLAPS
  9FT HYDRAULIC DOVETAIL W/LOCKING MECHANISM Power up and down, avoids heavy, dirty ramps and allows for ease of loading e ui ment of all ty es and weights. Will lift in excess of 10,000 lbs. WIRED/WIRELESS REMOTE CONTROLS
• ALL COMPONENTS STORED IN LOCKING SIDEMOUNT TOOLBOX! with greaseable hinges
• AC/DC DIRECT CHARGE ACCESSORY 5 AMP/ll0V FOR BOTH HYDRAULIC DOVETAIL AND WINC outlet for maintaining full charge on battery and prevention of battery freezing in the winter
• 17,S00LB WINCH PACKAGE(WATER PROOF), COMES W/1/2" H.D. WINCH PLATE UP ON TOP OF GOOSENECK, 12V DEEP CYCLE BATTERY, AC/DC DIRECT CHARGE ACCESSORY AND WIRED/WIRELESS REMOTE CONTROLS
• HEAVY DUTY 12" I-BEAM 22 LBS PER FT) Superior structural strength
• UNDER FRAME BRIDGE AND 6" PIPEBRIDGE - ADDS TO STRUCTURAL INTEGRITY, ENSURING NO TWISTING OF FRAME
• HEAVY DUTY 2 5/16" BULLDOG COUPLER (ADJUSTABLE HEIGHT) 5 place adjustments for ensuring correct height of trailer OR KING PIN COUPLER
• 16" CENTERS ON CROSSMEMBERS which ensures stronger deck on trailer
• 2 - 10,000LB HYDRAULIC JACKS- WIRED AND WIRELESS REMOTE CONTROLLED
• 2 MAX STEP/GRAB HANDLE -15" WIDE, BOTH SIDES
• DROP DOWN SPARE TIRE CARRIE - Spare tire carrier is inside/top of gooseneck with locking mechanism to prevent theft of your spare.
• STAKE POCKETS EVERY 2FT /RUB RAILS- easy to chain down or strap down loads
• 3 - 12,000LB DEXTER OIL BATH AXLES W/BRAKES, SELF ADJUSTING BRAKES No Need to occasionally jack up trailer to set brakes as they automatically adjust on forward stops. This is a safety feature with brakes always properly adjusted and will help your brakes last longer.
• "NEW" DEXTER HOSS SUSPENSION SYSTEM. SMOOTHS OUT THE TOUGHEST ROADS, 49" axles spread (better weight distribution), alignment/dog tracking adjustment, double spring assembly, Extended life on equalizer
• MODULAR WIRING - SEVERE ROAD WIRING PACKAGE UPGRADE State of the art wiring, no plastic clips joining wires, lights, etc. Comes with breakaway battery wiring kit.
• COLD WEATHER WIRING HARNESS UPGRADE - CERTIFIED TO -85°C Cord never stiff, won't crack, all sealed
• TREATED WOOD DECK
• SHERWIN_WILLIAMS POWDURA ONE CURE EPOXY PRIMER - ensures longevity and durability of topcoat
• BLACK GLOSS POLYESTER POWDERCOAT PAINT
• SPARE TIRE/RIM

Applications:

• Heavy equipment transport (construction machinery, vehicles)
• Commercial and industrial trailers
• Material transport (steel beams, pallets)

2024 Load Trail Trailer Gooseneck Tri-Axle trailer

FINANCING AVAILABLE OAC

Delivery Available for additional cost
